X Series E70 X5 4.8i (N62TU) OFFRD
Unclip cover (1) on front seat.
Release screws (1).
Disconnect plug connections (2) and detach cable.
Remove thigh support (3) towards top.
Detach seat cover (1) in marked area on left and right.
Lever out left and right clips (2).
Installation:
If necessary, replace faulty clips.
Unhook seat cover (1) in area (2).
Disconnect plug connection (3).
Remove seat cover (1) complete with support.
RA Removing and installing/replacing seat cover for left or right front seat (sport
