X Series E70 X5 4.8i (N62TU) OFFRD
66 20 508
Removing and installing (replacing) control
unit (Park Distance Control)
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Necessary preliminary tasks:
•
Remove flap in luggage compartment panel on right
Fold insulating mat (1) to one side.
Disconnect plug connection (1).
Remove control unit (2).
RA Removing and installing (replacing) control unit (Park Distance Control)
BMW AG - TIS
08.02.2013 17:41
Issue status (12/2007) Valid only until next DVD is issued
