X Series E70 X5 4.8i (N62TU) OFFRD
84 11 519
Removing and installing or replacing eject
box
Special tools required:
•
00 9 340
Necessary preliminary tasks:
•
Remove fresh-air grille in rear cabin
•
Pull rear cabin air duct out of centre console
Open storage box cover.
Release screws (1) and feed out eject box holder (2).
Expose plug connections (1) and disconnect.
Remove eject box.
RA Removing and installing or replacing eject box
