X Series E83 X3 2.0d (N47) OFFRD
62 11 280
Removing and installing (replacing)
instrument cluster
Important!
Read and comply with notes on protection against
electrostatic discharge (ESD protection).
Note:
Extend steering wheel completely and lower.
Tape off instrument panel trim (1) and upper steering column
casing (2) with crepe tape.
Release screws (1).
Carefully pull back instrument cluster (2).
Disconnect associated plug connection.
Remove instrument cluster (2).
Replacement:
Carry out programming/coding.
RA Removing and installing (replacing) instrument cluster
BMW AG - TIS
06.02.2013 09:32
Issue status (12/2007) Valid only until next DVD is issued
