X Series E83 X3 2.0d (N47) OFFRD
11 42 Oil Filter and Pipes
Type
Thread
Tightening specification
Measure
1AZ Oil filter cap to oil filter housing
N47 / N47S
25 Nm
2AZ TC oil feed to crankcase
N47 / N47S
Replace banjo bolt, sealing
rings
22 Nm
3AZ TC oil return to crankcase
N47 / N47S
Hose clamp
3 Nm
4AZ H.P./L.P. TC oil feed to crankcase
N47S
M10
Replace double banjo bolt,
sealing rings
22 Nm
5AZ Oil feed H.P. to oil return L.P.
N47S
Hose clamp
3 Nm
AZD Oil Filter and Pipes
