X Series E83 X3 2.5Si (N52K) OFFRD
32 41 341
Replacing cooler return line for power
steering (M54, N46, N52)
Important!
Adhere to the utmost cleanliness. Do not allow any dirt to
enter the hydraulic system.
Seal off hydraulic lines with plugs.
Recycling:
Catch and dispose of hydraulic fluid in a suitable container.
Necessary preliminary tasks:
•
Draw off and dispose of hydraulic fluid from fluid reservoir
•
N46: Remove intake duct
•
M54, N52: Remove intake filter housing with fresh-air duct
Remove fluid reservoir from mounting bracket/body.
Release hose clamp (1) and detach cooler return line (2) from
fluid reservoir.
Installation:
Make sure hydraulic line is laid without tension and with sufficient
spacing to adjoining components.
RA Replacing cooler return line for power steering (M54, N46, N52)
