X Series E83 X3 3.0i (M54) OFFRD
64 53 681
Replacing line from desiccant bottle to
evaporator (N47)
Warning!
Risk of injury!
Refrigerant circuit is under high pressure!
Follow safety instructions for handling R 134a refrigerant .
Avoid contact with refrigerant and refrigerant oil.
Follow safety instructions for handling refrigerant oil.
Important!
Risk of damage!
Restart engine only when A/C system has been correctly
filled.
Follow instructions for opening and replacing parts in
refrigerant circuit.
If A/C system is opened for more than 24 hours:
Replace desiccant insert for A/C system
Necessary preliminary tasks:
•
Drawing off, evacuating and filling the A/C system are not
included in the time value given for this work operation
•
If necessary, remove microfilter housing
•
Remove acoustic cover at front
•
Remove fluid reservoir for windscreen washer system
Release screws (1) and remove refrigerant line.
Installation:
Replace sealing rings and moisten with refrigerant oil.
Tightening torque 64 53 6AZ
.
RA Replacing line from desiccant bottle to evaporator (N47)
