X Series E83 X3 3.0i (M54) OFFRD
65 12 072
Removing and installing (replacing) amplifier
(Top hi-fi system)
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Necessary preliminary tasks:
•
Remove luggage compartment wheel arch trim on left.
Unfasten plug connection (1) and disconnect.
Release screws (2).
Remove amplifier (3) with holder in direction of arrow.
Release screw (1).
Fold back retaining bracket (2) in direction of arrow and remove.
Remove amplifier (3) from holder (4).
RA Removing and installing (replacing) amplifier (Top hi-fi system)
BMW AG - TIS
17.02.2013 04:14
Issue status (12/2007) Valid only until next DVD is issued
