Drive Belt: Service and Repair

Drive Belt Replacement (L26) (3.8L)

Removal Procedure

1. Lift or rotate the drive belt tensioner using a 15 mm box end wrench on the pulley nut.
2. Remove the drive belt.

Installation Procedure

1. Lift or rotate the drive belt tensioner using a 15 mm box end wrench on the pulley nut.
2. Install the drive belt.
