Lucerne V6-3.8L (2007)
Drive Belt: Service and Repair
Drive Belt Replacement
Removal Procedure
1. Using a 15 mm box end wrench on the pulley nut, rotate the drive belt tensioner (1) counterclockwise.
2. Remove the drive belt (2).
Installation Procedure
Important: After a NEW drive belt is installed, ensure that the mark on the drive belt tensioner is within the range indicated on the tensioner
housing.
1. Using a 15 mm box end wrench on the pulley nut, rotate the drive belt tensioner (1) clockwise.
2. Install the drive belt (2).
