Lucerne V6-3.9L (2009)
Note: The rear hoist pads must not contact the rocker panels or floor pan.
Position the pads under the body side rocker pinch welds (1) or the rear crossmember support (2).
Suspension Contact Hoist
Front Lift
Caution: Ensure that the front suspension-contact lift points contact the lower control arms ONLY where identified. Failure to follow this precautionary
step could result in damage to the lower control arm stabilizer link bracket.
When lifting the vehicle with a suspension-contact lift, place the front post lift points at the lower control arms (1).
Rear Lift
Position the suspension contact rear lift under the rear tire and wheel assemblies.
Jacking
When lifting a vehicle with a vehicle jack or a floor jack, block the wheels at the opposite end from which you are lifting. Use jack stands to provide
additional support.
Under the Front Suspension Crossmember
Position the floor jack pad under the front frame rail reinforcements.
