Rendezvous V6-3.5L (2007)
2. Install the fascia outer support.
3. Install the grille to the fascia. Refer to Fascia Grille Replacement .
4. Position the fascia to the vehicle.
5. Align the alignment pins of the fascia to the front fenders and moldings.
6. Engage the ball socket to the ball on the front fender.
7. Install the push-in the retainers starting at the center, to the front upper bumper fascia support.
Notice: Refer to Fastener Notice .
8. Install the bolts to the front fascia at the front fenders.
Tighten the front fascia bolts to 10 N.m (89 lb in).
Important: Push the retainer tabs up and against the front bumper energy absorber.
9. Install the push-in retainers to the fascia at the energy absorber.
10. Install the fog lamps. Refer to Front Fog Lamp Replacement (Rendezvous) .
11. Install the headlamps. Refer to Headlamp Replacement
12. Install the front fender liners. Refer to Front Fender Liner Replacement .
