Rendezvous V6-3.5L (2007)
Sound Proofing / Insulation: Service and Repair
Front Fender Insulator Replacement
Removal Procedure
1. Remove the front fender liner. Refer to Front Fender Liner Replacement .
2. Remove the front fender insulator from the stud, by pulling off.
3. Remove the front fender insulator from the inner fender.
Installation Procedure
Important: The front fender insulator must be kept near the flange of the front fender wheel opening to avoid interference with the front
door edge.
1. Install the front fender insulator to the stud in the inner fender, pressing into place until fully seated.
2. Install the front fender liner. Refer to Front Fender Liner Replacement .
