Rendezvous AWD V6-3.5L VIN L (2006)
Accumulator: Service and Repair
Accumulator and 2-1 Manual Servo Replacement
Removal Procedure
1. Raise and support the vehicle.
2. Remove the oil pan.
3. Remove the filter.
4. Remove the accumulator cover bolts (131).
5. Remove the manual 2-1 band servo cover bolts (103).
6. Use a large flat-bladed tool in order to gently pry the lube oil pipe retainer (129) from the case.
7. Remove the lube oil pipe (130) from the front differential carrier internal gear lube hole.
8. Remove the accumulator (132).
9. Remove the manual 2-1 band servo cover (104).
