Rendezvous AWD V6-3.6L VIN 7 (2004)
Air Register: Service and Repair
Air Outlet Replacement - Center
AIR OUTLET REPLACEMENT - CENTER
REMOVAL PROCEDURE
1. Remove the I/P assembly.
2. Remove the center air distribution duct nuts.
3. Remove the center air distribution duct from the I/P carrier.
INSTALLATION PROCEDURE
1. Position the center air distribution duct to the I/P carrier.
NOTE: Refer to Fastener Notice in Service Precautions.
2. Install the center air distribution duct nuts.
Tighten
Tighten the nuts to 10 N.m (89 lb in).
3. Install the I/P assembly.
