Rendezvous FWD V6-3.5L VIN L (2006)
![background image](/buick/rendezvous_fwd/v6-3.5l_vin_l/Page-3090001.png)
Scuff Plate: Service and Repair
Door Sill Plate Replacement - Front
DOOR SILL PLATE REPLACEMENT - FRONT
REMOVAL PROCEDURE
1. Remove the front door sill plate.
2. Remove the front door sill plate from the door sill.
3. Remove the front door sill plate push-in retainers if required.
INSTALLATION PROCEDURE
1. Install the front door sill plate push-in retainers and the 4-way locator, pressing in place until fully seated.
2. Align the front door sill plate to the 4-way locator and the push-in retainers.
3. Install the front door sill plate to the push-in retainers, applying pressure to secure at all tab locations.
