Riviera V6-231 3.8L VIN C SFI (1989)

Page 1
background image

Hydraulic Assembly: Symptom Related Diagnostic Procedures
Chart D-2, Hydraulic Unit Functional Check

Fig. 41  Chart D-2, Hydraulic Unit Functional Check (Part 1 Of 2)
