Skylark L4-138 2.3L SOHC VIN 3 MFI QUAD 4 (1992)
Electronic Brake Control Module: Service and Repair
Fig. 68 ECU Assembly Removal
1.
Disconnect battery ground cable.
2.
Disconnect ECU electrical connectors, Fig. 68.
3.
Remove ECU to dash panel attaching screws, then the ECU from dash panel.
4.
Reverse procedure to install, ensure all four plastic grommets are located properly and torque screws to 14 inch lbs.
