Skylark L4-138 2.3L SOHC VIN 3 MFI QUAD 4 (1992)

Page 5
background image

This bulletin updates Diagnostic Charts. The updated charts represent engineering changes in the fuel pump relay system. Included are enhanced
diagnostic charts. The charts are as follows:

ECM Wiring Diagram (1 of 3).

Chart A-3 - Engine Cranks But Will Not Run.

Chart A-5 - Engine Cranks But Will Not Run.
