Avalanche 4WD V8-5.3L (2011)
10. Position the drain pan under the oil filter (437).
11. Remove the oil filter.
12. Ensure that the oil filter gasket is still on the old filter if not, remove the oil filter gasket from the oil pan.
Installation Procedure
1. Apply clean engine oil to the NEW oil filter seal.
Caution: Refer to Fastener Caution See: Service Precautions/Vehicle Damage Warnings/Fastener Caution.
2. Install the NEW oil filter (437) and tighten to 30 Nm (22 lb ft).
3. Tighten the oil pan drain plug (430) to 25 Nm (18 lb ft).
4. Remove the oil drain pan from under the vehicle.
5. Lower the vehicle.
6. Fill the engine with new engine oil. Refer to Approximate Fluid Capacities See: Specifications and Fluid and Lubricant Recommendations See: .
