Aveo L4-1.6L (2008)
Accumulator HVAC: Service and Repair
Accumulator Replacement
Removal Procedure
Caution: Refer to Battery Disconnect Caution (See: Starting and Charging/Battery/Service Precautions/Technician Safety Information/Battery
Disconnect Caution).
1. Disconnect the negative battery cable.
2. Recover the refrigerant. Refer to Refrigerant Recovery and Recharging (See: Service and Repair).
3. Remove the screw that secures the receiver-dryer band clamp.
4. Remove the receiver-dryer with the bolts.
5. Drain the oil from the receiver-dryer into a container. Measure the amount of oil drained from the receiver dryer and then discard this used oil.
Installation Procedure
