Aveo L4-1.6L (2008)
Vacuum Reservoir: Service and Repair
Intake Manifold Tuning Valve Vacuum Reservoir Replacement
Removal Procedure
1. Remove the vacuum hoses from the intake manifold (IMT) vacuum reservoir (1).
2. Remove the IMT valve reservoir (1).
Installation Procedure
1. Install the IMT valve reservoir (1).
2. Install the vacuum hoses to the IMT valve reservoir (1).
