Aveo L4-1.6L (2008)
Air Cleaner Fresh Air Duct/Hose: Service and Repair
Air Cleaner Inlet Duct Replacement
Removal Procedure
Important: The intake air temperature sensor is no longer replaced as a seperate service item. If the intake air temperature sensor is
faulty, replacement of the entire air cleaner inlet duct will be necessary.
1. Turn OFF the ignition.
2. Disconnect the electrical connector from the intake air temperature (IAT) sensor.
3. Disconnect the breather tube from the air cleaner intake duct.
4. Loosen the clamps securing the air cleaner intake duct.
5. Remove air cleaner intake duct.
Installation Procedure
