Beretta L4-138 2.3L DOHC QUAD 4 HO MFI VIN A (1994)

Page 1
background image

Ignition Coil: Specifications

IGNITION COIL RESISTANCE

Primary Resistance .......................................................................................................................................................................................  Not Specified
Secondary Resistance ...................................................................................................................................................................10,000 ohms maximum

NOTE:  Secondary resistance measured across each coil's two towers with coil removed from vehicle.

NOTE:  Winding resistance (ohms at 80°F or 27°C)
