C Tahoe 2WD V8-5.3L VIN Z Flex Fuel (2002)
Intake Manifold: Service and Repair
Engine Sight Shield Replacement
Engine Sight Shield Replacement (4.8L, 5.3L, and 6.0L (LQ4)
Removal Procedure
1. Loosen the intake manifold sight shield bolt.
2. Remove the sight shield from the sight shield retainer.
3. If removal of the sight shield retainer is required, disconnect the accelerator control cable clip from the retainer.
4. Disconnect the cruise control cable clip from the retainer.
5. Remove the sight shield retainer bolts and the retainer, if required.
Installation Procedure
