Cobalt L4-2.2L (2008)
Timing Component Alignment Marks: Locations
^
Install the timing chain drive sprocket to the crankshaft with the timing mark in the 5 o'clock position.
Important:
^
There are 3 colored links on the timing chain. Two links are of matching color, and one link is of a unique color. Use the following procedure to
line up the links with the sprockets. Orient the chain so that the colored links are visible.
*
Always use new sprocket bolts.
^
Assemble the intake camshaft sprocket to the timing chain with the timing mark lined up with the uniquely colored link (1). Hand tighten a new
intake camshaft sprocket bolt.
