Cobalt L4-2.4L (2007)
Constant Velocity Joint: Service and Repair
Wheel Drive Shaft Inner Joint and Seal Replacement (GKN)
Wheel Drive Shaft Inner Joint and Seal Replacement (GKN)
Tools Required
J35910 Drive Axle Seal Clamp Pliers
Disassembly Procedure
1. Position wheel drive shaft bar in a soft jawed vise and clamp securely.
2. Using side cutters, remove and discard the small seal clamp.
3. Remove large seal retaining clamp using a flat-bladed tool and discard the clamp.
