Cobalt L4-2.4L (2007)
Seals and Gaskets: Service and Repair
Getrag 5 Speed - Manual Transmission
Front Wheel Drive Shaft Oil Seal Replacement
Front Wheel Drive Shaft Oil Seal Replacement
Tools Required
^
J 44385Differential Bearing Race and Seal Installer
^
J 7079-2 Non-threaded Driver Handle
^
SA9133T Axle Seal Puller
Removal Procedure
1. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle.
2. Remove the front wheel and tire assemblies. Refer to Tire and Wheel Removal and Installation (4 Lug Wheel) Tire and Wheel Removal and
Installation (5 Lug Wheel).
3. Remove the wheel driveshaft. Refer to Wheel Drive Shaft Replacement.
4. Use the SA9133T in order to remove the seal.
5. Inspect the seal bore for nicks or for burrs. Clean the bore with a fine grade sandpaper, if necessary.
Installation Procedure
1. Use the J 44385 and the J 7079-2 in order to install a new seal. Ensure that the seal is seated flush to the outer bore area.
2. Lubricate the seal with Dexron(R)-III transmission fluid Saturn P/N 21019223.
3. Install the wheel driveshaft. Refer to Wheel Drive Shaft Replacement.
4. Install the front tire and wheel assemblies. Refer to Tire and Wheel Removal and Installation (4 Lug Wheel) Tire and Wheel Removal and
