Cruze L4-1.4L Turbo (2011)
Crankshaft Main Bearing Seal: Service and Repair
Crankshaft Rear Oil Seal Replacement (Automatic Transmission)
Crankshaft Rear Oil Seal Replacement (Automatic Transmission)
Special Tools
*
EN-658-1 - Installer
*
EN-235-6 - Installer
For equivalent regional tools, refer to Special Tools (See: Tools and Equipment).
Removal Procedure
1. Open the hood.
2. Remove the automatic transmission flexplate. Refer to Automatic Transmission Flex Plate Replacement (See: Transmission and Drivetrain/Flex
Plate/Service and Repair).
3. Place a collecting basin underneath the vehicle.
4. Remove the crankshaft rear oil seal.
Installation Procedure
1. Install the crankshaft rear oil seal (1) with EN-235-6 - installer (2).
