Cruze L4-1.4L Turbo (2011)
Variable Valve Timing Solenoid: Service and Repair
Camshaft Position Actuator Solenoid Valve Replacement
Removal Procedure
1. Remove the air cleaner assembly. Refer to Air Cleaner Assembly Replacement (1.4L LUH and LUJ) (See: Fuel Delivery and Air Induction/Air
Cleaner Housing/Service and Repair).
2. Disconnect the intake camshaft position actuator solenoid valve wiring harness plug (3).
3. Disconnect the exhaust camshaft position actuator solenoid valve wiring harness plug (2).
4. Unclip ECM wiring harness (1) from camshaft cover.
5. Remove the 4 camshaft position actuator solenoid valve bolts (1).
