Timing Component Alignment Marks: Locations

Make

Chevrolet

Model

HHR

Engine

L4-2.0L Turbo

Year

2010

Section

Timing Component Alignment Marks › Locations

MaintenanceLocations · page 1 of 4

Timing Component Alignment Marks: Locations

For the complete procedure, please refer to Timing Chain.  See: Engine, Cooling and Exhaust/Engine/Timing Components/Timing Chain/Service and
Repair

Removal Procedure

7. Install a 24 mm wrench on the hex on the exhaust camshaft in order to hold the camshaft.

13. Install a 24 mm wrench on the hex on the intake camshaft in order to hold the camshaft.

Installation Procedure

1. If replacing the balance shaft timing chain, perform the following steps, if not proceed to step 10.
