HHR L4-2.0L Turbo (2010)
Battery Current Sensor: Service and Repair
Battery Current Sensor Replacement
Removal Procedure
1. Remove the negative battery cable. Refer to Battery Negative Cable Replacement (See: Battery/Battery Cable/Negative/Service and
Repair/Battery Negative Cable Replacement).
2. Remove the tape securing the battery current sensor to the negative battery cable.
3. Remove the battery current sensor from the negative battery cable.
Installation Procedure
