HHR L4-2.2L (2007)
Fuel Supply Line: Service and Repair
Fuel Hose/Pipes Replacement - Chassis
Fuel Hose/Pipes Replacement - Chassis
Removal Procedure
1. Relieve the fuel system pressure. Refer to Fuel Pressure Release (With CH 48027) Fuel Pressure Release (Without CH 48027).
2. Remove the air cleaner assembly.
3. Disconnect the fuel feed pipe from the fuel rail.
4. Cap or plug the fuel pipe and the engine fuel rail to prevent contamination.
5. Disconnect the evaporative emission (EVAP) pipe from the purge solenoid.
6. Cap or plug the EVAP pipe in order to prevent contamination.
7. Raise and support the vehicle. Refer to Vehicle Lifting.
8. Remove the evaporative emission (EVAP) canister, if necessary.
