Impala V6-3.9L (2007)
Ignition Control Module: Locations
Engine Controls Component Views
Top of the Engine (LZE, LZ4, LZ9)
1 - Manifold Absolute Pressure (MAP) Sensor
2 - Throttle Body
3 - Intake Manifold
4 - Intake Manifold Tuning (IMT) Valve Solenoid (LZ9)
5 - Camshaft Position (CMP) Sensor
6 - Heated Oxygen Sensor (HO2S) 1
7 - Ignition Control Module (ICM)
Rear of the Engine (LZE, LZ4, LZ9)
