Hose/Line HVAC: Specifications
- Make
- Chevrolet
- Model
- Lumina
- Engine
- V6-3.1L VIN J
- Year
- 2000
- Section
- Hoses › Hose/Line HVAC › Specifications
Hose/Line HVAC: Specifications
Liquid/Suction Line Bracket Bolt
6 Nm
Suction Line at Block Fitting Bolt
16 Nm
Suction Line Nut at Accumulator
47 Nm
Liquid Line at Block Fitting Bolt
16 Nm
Liquid Line Nut at Condenser
27 Nm
Liquid Line Nut at Orifice
27 Nm
Liquid/Suction Line Bracket Bolt
6 Nm
Accumulator Bracket Bolt
4 Nm
Compressor Hose Bolt/Nut to Compressor
33 Nm
Compressor Hose Nut to Accumulator
16 Nm
Compressor Hose Nut to Condenser
27 Nm
Compressor Upper/Lower Mounting Bolts
50 Nm
Suction Line Nut at Accumulator
47 Nm
