Malibu L4-2.4L Hybrid (2008)
Fuse Block: Locations
Front of Vehicle/Engine Compartment Component Views
Front of Vehicle/Engine Compartment Component Views
Underhood Components (+LE5+LZ4+LY7)
1 - Windshield Wiper Motor
2 - Brake Fluid Pressure Sensor
3 - Electronic Brake Control Module (EBCM)
4 - Fuse Block - Underhood
5 - Transmission Control Module (TCM) (ME7/MN5)
6 - Battery
7 - Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor
8 - Engine Control Module (ECM) (LE5/LY7/LZ4)
9 - Brake Fluid Level Switch
Underhood Components (+LAT)
