Malibu L4-2.4L Hybrid (2008)
Crankshaft Position Sensor: Service and Repair
Crankshaft Position Sensor Replacement
Crankshaft Position Sensor Replacement
Removal Procedure
1. Remove the starter.
2. Disconnect the engine wiring harness electrical connector (1) from the crankshaft position (CKP) sensor.
3. Remove the CKP sensor bolt.
4. Remove the CKP sensor.
Installation Procedure
