Malibu V6-3.6L (2010)
Fuel Rail: Service and Repair
Fuel Injector and Fuel Rail Replacement
Removal Procedure
Warning: Refer to Gasoline/Gasoline Vapors Warning (See: Fuel/Service Precautions).
1. Remove the fuel injector sight shield. Refer to Fuel Injector Sight Shield Replacement (See: Fuel Injector/Service and Repair/Fuel Injector Sight
Shield Replacement).
2. Disconnect the engine wiring harness electrical connector (1) from the fuel injector wiring harness electrical connector.
3. Disconnect the fuel feed pipe (1) quick connect fitting from the fuel rail. Refer to Metal Collar Quick Connect Fitting Service (See: Fuel Line
Coupler/Service and Repair/Metal Collar Quick Connect Fitting Service).
4. Remove the upper intake manifold. Refer to Upper Intake Manifold Replacement (See: Engine, Cooling and Exhaust/Engine/Intake
Manifold/Service and Repair/Upper Intake Manifold Replacement).
