Malibu V6-3.6L (2010)
Fuel Gauge Sender: Service and Repair
Fuel Tank Module Replacement
Special Tools
J 45722 Fuel Sender Lock Ring Wrench
Removal Procedure
1. Remove the fuel tank. Refer to Fuel Tank Replacement (See: Powertrain Management/Fuel Delivery and Air Induction/Fuel Tank/Service and
Repair/Removal and Replacement).
2. Disconnect the fuel tank fuel pump module wiring harness electrical connectors (1, 2) from the fuel pressure sensor and the module.
3. Disconnect the fuel tank vent pipe quick connect fittings (3, 4) from the module. Refer to Plastic Collar Quick Connect Fitting Service (See:
Powertrain Management/Fuel Delivery and Air Induction/Fuel Line Coupler/Service and Repair/Plastic Collar Quick Connect Fitting Service).
