Malibu V6-3.9L (2007)
Glove Box Lamp Switch: Service and Repair
Instrument Panel Dimmer Switch Replacement
Removal Procedure
1. Remove the left instrument panel (I/P) trim panel.
2. Remove the I/P dimmer switch wire harness connector.
3. Remove the I/P dimmer switch.
Installation Procedure
1. Install the I/P dimmer switch.
2. Install the I/P dimmer switch wire harness connector.
3. Install the left I/P trim panel.
