Monte Carlo V8-5.3L (2007)
When lifting the vehicle with a frame-contact lift, place the front lift pads at the front pinchweld flanges.
Rear Lift Pads
When lifting the vehicle with a frame-contact lift, place the rear lift pads at the rear pinchweld flanges.
Vehicle Lifting-Suspension Contact Lift
When lifting the vehicle with a suspension-contact lift, place the front post lift points at the lower control arms in the area shown (1). Lift the rear of the
vehicle with the rear post lift points ONLY under the rear wheels.
Vehicle Jacking
Under the Front Frame
When lifting the front of the vehicle with a floor jack, place the floor jack lift pad at the center of the front frame.
Under the Center of the Rear Suspension
