Silverado SS AWD V8-6.0L VIN N (2003)
Seals and Gaskets: Service and Repair
NVG 261-NP2 Transfer Case
Transfer Case Output Shaft Seal Replacement - Front
Transfer Case Output Shaft Seal Replacement - Front
Tools Required
^
J8092 Drive Handle
^
J43484 Output Shaft Seal Installer
Removal Procedure
1. Remove the transfer case shield, if equipped.
2. Remove the front propeller shaft.
3. Insert a flat-tipped screwdriver into the inner race.
4. Pry the inner race back.
5. Insert a small pry bar into the inner race
