Suburban 1/2 Ton 4WD V8-5.3L VIN T (2004)
Seat Cushion: Procedures
Blower Replacement - Ventilation Heat and Cool - Front Seat Cushion
BLOWER REPLACEMENT - VENTILATION HEAT AND COOL - FRONT SEAT CUSHION
REMOVAL PROCEDURE
1. Remove the seat cushion.
2. Disconnect the blower electrical connector.
3. Cut the tie straps (1) securing the blower bracket to the seat cushion frame.
4. Remove the blower and bracket assembly from the seat cushion.
5. Drill the rivets (2) retaining the blower (3) to the bracket (1).
CAUTION: Eye protection must be worn when drilling rivets to reduce the chance of personal injury.
