Suburban 1/2 Ton 4WD V8-5.3L VIN Z Flex Fuel (2006)
Flex Plate: Specifications
Flex Plate Bolts - First Pass........................................................................................................................................................................ 20 Nm (15 ft. lbs.)
Flex Plate Bolts - Second Pass.................................................................................................................................................................... 50 Nm (37 ft. lbs.)
Flex Plate Bolts - Final Pass..................................................................................................................................................................... 100 Nm (74 ft. lbs.)
