Tracker 2WD L4-1.6L VIN 6 (2000)
Alternator: Electrical Specifications
Amperage
Generator Specifications:
Brush Length--Standard ............................................................................................................................................................................... 16 mm 0.63 in
Brush Length--Minimum ............................................................................................................................................................................... 2 mm 0.08 in
Condenser Capacity ..................................................................................................................................................................................... 0.5 microfarads
Direction of Rotation ................................................................................................................................................ Clockwise (Viewed From Pulley Side)
Maximum Generator Output ........................................................................................................................................................................ 60 and 70 amps
Maximum Generator Speed .............................................................................................................................................................................. 18,000 RPM
Normal Operating Voltage ........................................................................................................................................................................................ 12 volts
Polarity Negative (-) Ground No-Load Generator Speed .................................................................................................................................... 1,300 RPM
Regular Voltage ............................................................................................................................................................................................. 14.4-15.0 volts
Rotor Slip Ring Resistance ............................................................................................................................................................................... 2.5-2.9 ohms
Temperature Range .................................................................................................................................................................... -30 to 90°C -22 to 194°F
Voltage
Voltage
Charging Voltage
14.4-15.0 Volts
