Tracker 4WD L4-2.0L VIN C (1999)
1. Install the fan/clutch assembly to the vehicle.
2. Install the shroud and secure with the 4 clips.
3. Reposition and attach the power steering reservoir to the power steering reservoir bracket.
4. Install the fan/clutch assembly to the pulley hub.
Notice: Refer to Fastener Notice in Service Precautions.
5. Install the 4 fan nuts. Use a second wrench to hold the fan shaft.
Tighten the fan nuts to 11 Nm (97 inch lbs.).
6. Connect the negative battery cable.
Tighten the battery cable bolt to 15 Nm (11 ft. lbs.).
