Uplander AWD V6-3.5L VIN 8 (2005)
2. Loosen rear lower control arm mounting nuts (3, 4)
3. Adjust camber with cam bolt (1).
4. Confirm correct camber value.
5. Check toe alignment and adjust if required.
Installation Procedure
Notice: Refer to Fastener Notice in Service Precautions.
1. Tighten the lower control arm mounting nuts (3, 4).
^
Tighten the nut (3) to 125 Nm (107 ft. lbs.).
^
Tighten the nut (4) to 50 Nm (37 ft. lbs.).
2. Test drive the vehicle.
Rear Toe Adjustment
Important: Make any adjustments to camber before setting toe.
1. Loosen the jam nut (6) at the rear wheel tie rod.
2. Adjust the toe to the proper setting by turning the inner link adjustment hex (4).
Notice: Refer to Fastener Notice in Service Precautions.
3. When the toe adjustment is correct, tighten the jam nut.
^
Tighten the nut to 62 Nm (45 ft. lbs.).
