Concorde V6-3.5L VIN F (1994)
Brake Switch (Cruise Control): Testing and Inspection
1. Remove stop lamp/speed control switch, then inspect continuity as follows:
a. With switch plunger released, there should be continuity between pin No. 5 and pin No. 6.
b. With switch plunger depressed, there should be continuity between pin No. 1 and pin No. 2 and also between pin No. 3 and pin No. 4.
Fig. 21 Stop Lamp Switch
2. If continuity is not as specified, replace stop lamp switch.
