Control Assembly: Service and Repair

REMOVAL

1. Remove the ash receiver assembly, if necessary.

Lower Center Bezel

2. Remove the lower center bezel and remove the mounting screws from sides of control.
3. Remove the control and disconnect the two electrical connectors.

INSTALLATION

-

For installation, reverse the above procedures.
