Concorde V6-3.5L VIN F (1994)
ABS Main Relay: Service and Repair
Fig 72 System Relay/Warning Lamp Relay Location
The main relay and pump motor relay are serviced as an assembly with the relay mounting bracket. The relay bracket is mounted to the side of the power
distribution center (PDC).
1. Remove relay electrical connector by pulling straight down on wiring harness.
2. Remove relays and bracket from side of PDC.
3. Reverse procedure to install.
